ARB BASE Rack Prewired Wiring Kit 3 Circuit Roof Entry 1780400
SKU: BHWQ_1780400
$96.00
SAVE %
or 4 interest-free payments of $24.00 with Shop Pay
You're on the list - we'll email you when it's back.
Estimate Shipping
Ships worldwide
Estimated for this item. Final rates are confirmed at checkout.
Free US ShippingAll US orders
30-Day ReturnsHassle-free
WarrantyLifetime tech support
The ARB 1780400 is a prewired 3 circuit wiring kit for the ARB BASE Rack. It provides a safe, sealed way to bring 12V power from inside the vehicle up through the roof to accessories mounted on the BASE Rack, such as rooftop lighting and communication devices, without custom wiring.
Features
- Six factory-installed wires (3 circuits) for sealed wiring
- Red pair: 2.0 mm2 wire rated 25A; green and yellow pairs: 0.5 mm2 wire rated 11A each
- 4.0 m of wire for outside the roof and 2.5 m for inside the vehicle
- High quality automotive wire to JASO standards
- Roof entry through 2 x 7 mm and 1 x 25 mm drilled holes; the 25 mm hole passes Deutsch DT-02 connectors
- Mount locations developed to allow for side curtain airbags and other obstructions on popular vehicles
- Exit grommets suit standard 10 mm (3/8 in) and 13 mm (1/2 in) OD conduit
Specifications
- Part number: 1780400
- Brand: ARB
- Circuits: 3 (6 wires)
- Entry: Through the vehicle or canopy roof
- Wire: JASO standard automotive wire
- UPC: 9332018077103
What's Included
- Prewired roof grommet with bonded wires
- Rubber outer boot with 300 mm sheath
- BASE Rack entry, exit and direct exit grommets
- Fasteners, cable ties and edge clips
